Lift and Access Equipment 2024 Equipment Guide | Page 17

AERIAL LIFTS IC Scissor Lifts
Additions and Updates for Next Year ' s Equipment Guide?
AERIAL LIFTS Manually Propelled Vertical Lifts

AERIAL LIFTS IC Scissor Lifts

PLATFORM
STOWED
PLATFORM LENGTH
PLATFORM
TYPE OF
GRADEABILITY
OUTSIDE
OPERATING
RAISE /
TRAVEL
HEIGHT
PLATFORM
EXTENDED SINGLE /
CAPACITY
DRIVE
2WD / 4WD
TURNING RADIUS
WEIGHT
LOWER TIME
SPEED
POWER
MAKE
MODEL
( FT-IN)
SIZE( IN)
DUAL DECK( IN)
( LBS)
2WD / 4WD
(%)
( FT-IN)
( LBS)
( SEC)
( MPH)
SOURCE
Snorkel
S2770RTE
27 ' 0 "
116 " x 62 "
157 " / –
1,250
4WD
– / 35
16 ' 3 "
6,172
26 / 30
2.8
Battery
Snorkel
S3370RTE
33 ' 0 "
116 " x 62 "
157 " / –
1,000
4WD
– / 35
16 ' 3 "
7,980
50 / 60
2.8
Battery
Snorkel
S3970RTE
39 ' 0 "
116 " x 62 "
157 " / –
771
4WD
– / 35
16 ' 3 "
8,355
50 / 60
2.8
Battery
Snorkel
S9031RT-HC
31 ' 0 "
192 " x 90 "
246 " / 324 "
4,000
4WD
– / 50
18 ' 6 "
15,000
30 / 20
4.2
Diesel
Snorkel
S9033RT
33 ' 0 "
141 " x 90 "
195 " / 264 "
2,500
4WD
– / 50
17 ' 4 "
16,302
45 / 30
4.2
Diesel
Snorkel
S9043RT
43 ' 0 "
141 " x 90 "
195 " / 264 "
1,500
4WD
– / 50
17 ' 4 "
17,946
50 / 40
4.2
Diesel
Snorkel
S9043RT-HC
43 ' 0 "
192 " x 90 "
246 " / 324 "
3,500
4WD
– / 50
18 ' 6 "
17,000
40 / 25
4.2
Diesel
Snorkel
S9053RT
53 ' 0 "
141 " x 90 "
195 " / 264 "
1,500
4WD
– / 40
17 ' 4 "
19,448
55 / 40
4.2
Diesel
Snorkel
S9056RT-HC
56 ' 0 "
192 " x 90 "
246 " / 324 "
2,500
4WD
– / 50
18 ' 6 "
20,000
55 / 35
4.2
Diesel
Snorkel
S9070RT-HC
70 ' 0 "
192 " x 90 "
246 " / 324 "
2,000
4WD
– / 50
18 ' 6 "
25,500
70 / 40
4.2
Diesel
Snorkel
SL26RT
25 ' 6 "
144 " x 68 "
180 " / –
1,500
4WD
– / 50
18 ' 6 "
7,826
21 / 32
4
Diesel
Snorkel
SL26RTE
25 ' 6 "
144 " x 68 "
180 " / –
1,500
4WD
– / 50
18 ' 6 "
7,826
21 / 32
3.3
Battery
Snorkel
SL30RT
29 ' 4 "
167 " x 68 "
–
1,300
4WD
– / 50
18 ' 6 "
7,495
24 / 36
4
Diesel
Snorkel
SL30RTE
29 ' 4 "
167 " x 68 "
–
1,300
4WD
– / 50
18 ' 6 "
7,605
24 / 36
3.3
Battery
Zoomlion ZS5390RT 52 ' 6 " 157 " x 72 " 208 " / – 1,500 4WD – / 40 19 ' 0 " 19,070 60 / 65 4 Diesel

Additions and Updates for Next Year ' s Equipment Guide?

Contact Wendy Zurn- wendy. zurn @ catcomnet. com- 515-574-2312
Updates / Additions Due by:
September 18, 2025

AERIAL LIFTS Manually Propelled Vertical Lifts

PLATFORM
PLATFORM
PLATFORM
STOWED
OUTRIGGER STANCE
OPERATING
HEIGHT
DIMENSIONS
CAPACITY
DIMENSIONS
DIMENSIONS
WEIGHT
MAKE
MODEL
( FT-IN)
( L x W)( FT-IN)
( LBS)
( L x W x H)( FT-IN)
( FT-IN)
( LBS)
Absolute E-Z Up ISP-7M 7 ' 1 " 26 " x 24 " 287 + 198 3 ' 10 " x 2 ' 5 " x 4 ' 10 " – 617 Bravi Platforms SPIN-GO 7 ' 11 " 45 " x 28 " 286 45 " x 28 " x 58 " 45 " x 28 " 617
Genie
AWP-20S
20 ' 1 "
27 " x 26 "
350
4 ' 1 " x 2 ' 5 " x 6 ' 6 "
5 ' 1 " x 4 ' 5 "
766
Genie
AWP-20S Narrow
20 ' 1 "
26 " x 20 "
–
5 ' 3 " x 1 ' 10 " x 6 ' 7 "
5 ' 4 " x 4 ' 2 "
749
Genie
AWP-20S RT
20 ' 1 "
27 " x 26 "
–
5 ' 3 " x 2 ' 6 " x 6 ' 7 "
5 ' 4 " x 4 ' 2 "
749
Genie
IWP-20S
20 ' 3 "
27 " x 26 "
350
5 ' 0 " x 2 ' 8 " x 6 ' 4 "
–
1,345
Genie
IWP-25S
24 ' 11 "
27 " x 26 "
350
5 ' 0 " x 2 ' 8 " x 6 ' 4 "
–
1,390
Genie
AWP-25S
24 ' 11 "
27 " x 26 "
350
4 ' 3.5 " x 2 ' 5 " x 6 ' 6 "
5 ' 1 " x 4 ' 5 "
817
Genie
AWP-25S Narrow
24 ' 11 "
26 " x 20 "
–
5 ' 3 " x 1 ' 10 " x 6 ' 7 "
5 ' 4 " x 4 ' 2 "
780
Genie
AWP-25S RT
24 ' 11 "
27 " x 26 "
–
5 ' 3 " x 2 ' 6 " x 6 ' 7 "
5 ' 4 " x 4 ' 2 "
780
Genie
AWP-30S
29 ' 6 "
27 " x 26 "
350
4 ' 5 " x 2 ' 5 " x 6 ' 6 "
5 ' 9 " x 5 ' 1 "
867
Genie
AWP-30S Narrow
29 ' 6 "
26 " x 20 "
–
5 ' 3 " x 1 ' 10 " x 6 ' 7 "
6 ' 0 " x 5 ' 0 "
818
Genie
AWP-30S RT
29 ' 6 "
27 " x 26 "
–
5 ' 3 " x 2 ' 6 " x 6 ' 7 "
6 ' 0 " x 5 ' 0 "
818
Genie
IWP-30S Wide
29 ' 6 "
27 " x 26 "
350
5 ' 0 " x 3 ' 4 " x 6 ' 4 "
–
1,530
Genie
AWP-36S
36 ' 5 "
27 " x 26 "
350
4 ' 7 " x 2 ' 5 " x 9 ' 1.5 "
6 ' 11 " x 6 ' 3 "
1,107
Genie
AWP-40S
40 ' 4 "
27 " x 26 "
300
4 ' 8 " x 2 ' 5 " x 9 ' 1.5 "
7 ' 5 " x 6 ' 9 "
1,130
GMG 1030-PA 9 ' 11 " 45.3 " x 29.3 " 530 48.4 " x 29.9 " x 72.8 " – 1,025 Hy-Brid Lifts PA-1030 10 ' 0 " 42 " x 20.5 " 530 4 ' 3 " x 2 ' 5.5 " x 5 ' 9 " – 893
JLG
EcoLift 50
4 ' 11 "
28 " x 23.6 "
330
3 ' 3 " x 27.5 " x 5 ' 1 "
–
397
JLG
EcoLift 70
7 ' 3 "
33.4 " x 25.4 "
330
4 ' 2 " x 27.5 " x 6 ' 4 "
–
672
JLG
830P
8 ' 2 "
39.3 " x 28.7 "
440
47 " x 29.5 " x 61.4 "
–
628
JLG
1030P
10 ' 2 "
60 " x 30 "
550
5 ' 3 " x 2 ' 6 " x 6 ' 1 "
N / A
753
JLG
25AM
25 ' 2 "
28 " x 26 "
350
4 ' 1 " x 2 ' 5 " x 6 ' 5.5 "
5 ' 2 " x 4 ' 5 "
905
JLG
30AM
29 ' 7 "
26 " x 26 "
300
4 ' 4 " x 2 ' 5 " x 6 ' 6 "
6 ' 7 " x 6 ' 7 "
1030
JLG
38AM
38 " 0 "
26 " x 26 "
300
4 ' 10 " x 2 ' 5 " x 8 ' 8 "
7 ' 2 " x 7 ' 0 "
1265
ReechCraft
PowerLift M20
14 ' 3 "
30 " x 26 "
350
4 ' 5 " x 2 ' 6 " x 5 ' 9 "
5 ' 5 " x 4 ' 4 "
278
ReechCraft
PowerLift PL60
19 ' 6 "
30 " x 26 "
350
4 ' 5 " x 2 ' 6 " x 5 ' 9 "
5 ' 7 " x 5 ' 4 "
310
Snorkel
S3006P
6 ' 6 "
43.3 " x 20.4 "
529
3 ' 11 " x 2 ' 4 " x 5 ' 6 "
–
682
Snorkel
S3008P
8 ' 2 "
43.3 " x 20.4 "
500
3 ' 11 " x 2 ' 4 " x 5 ' 10 "
–
770
Snorkel
S3010P
9 ' 10 "
43.3 " x 20.4 "
430
3 ' 11 " x 2 ' 4 " x 5 ' 10 "
–
815
Snorkel
S3210P
9 ' 10 "
47 " x 32 "
529
3 ' 11 " x 2 ' 8 " x 5 ' 10 "
-
1,036
Snorkel
UL25
24 ' 11 "
22 " x 26 "
350
4 ' 2 " x 2 ' 5 " x 6 ' 6 "
6 ' 10 " x 6 ' 6 "
859( AC) / 926( DC)
Snorkel
UL32
31 ' 9 "
22 " x 26 "
300
4 ' 4 " x 2 ' 5 " x 8 ' 3 "
6 ' 10 " x 6 ' 6 "
959( AC) / 1,025( DC)
Snorkel
UL40
40 ' 0 "
22 " x 26 "
300
4 ' 4 " x 2 ' 5 " x 9 ' 6 "
9 ' 8 " x 9 ' 4 "
1,036( AC) / 1,102( DC)
Specifications collected from manufacturers ' published data. Data is subject to change without notice.
Equipment Guide- October 2024 l
17
