MAXIMUM LIFT |
MAXIMUM |
LIFT CAPACITY |
SIDESHIFT |
ENGINE MAKE |
WHEELBASE |
GROUND |
TURNING RADIUS |
OPERATING |
||
CAPACITY @ 24 " |
LIFT HEIGHT |
@ MAXIMUM |
LEFT & RIGHT |
& MODEL |
2WD / 4WD |
CLEARANCE |
2WD / 4WD |
WEIGHT |
||
MAKE |
MODEL |
LOAD CENTER( LBS) |
( FT-IN) |
FORK HEIGHT( LBS) |
( IN) |
( GROSS HP) |
( FT-IN) |
( IN) |
( FT-IN) |
2WD / 4WD( LBS) |
Liftking Mfg Corp |
LK 16M22 |
16,000 |
14 ' 0 " |
16,000 |
3 " + 3 " |
Perkins 1104D-44T( 127) |
8 ' 5 " / – |
12 " |
16 ' 6 " / – |
22,000 / – |
Liftking Mfg Corp |
LK 16M42 |
16,000 |
14 ' 0 " |
16,000 |
3 " + 3 " |
Perkins 1104D-44T( 127) |
– / 8 ' 5 " |
12 " |
– / 16 ' 6 " |
– / 22,000 |
Liftking Mfg Corp |
LK 16P44 |
16,000 |
14 ' 0 " |
16,000 |
3 " + 3 " |
Perkins 1104D-44T( 127) |
– / 7 ' 10 " |
12 " |
– / 15 ' |
– / 21,800 |
Liftking Mfg Corp |
LK 20M22 |
20,000 |
14 ' 0 " |
20,000 |
3 " + 3 " |
Perkins 1104D-44T( 127) |
9 ' 6 " / – |
12 " |
17 ' 6 " / – |
28,000 / – |
Liftking Mfg Corp |
LK 20M42 |
20,000 |
14 ' 0 " |
20,000 |
3 " + 3 " |
Perkins 1104D-44T( 127) |
– / 9 ' 6 " |
12 " |
– / 17 ' 6 " |
– / 28,000 |
Liftking Mfg Corp |
LK 20P44 |
20,000 |
16 ' 0 " |
20,000 |
3 " + 3 " |
Perkins 1104D-E44TA( 142) |
– / 11 ' 3 " |
14 " |
– / 19 ' 6 " |
– / 38,500 |
Liftking Mfg Corp |
LK 25P44 |
25,000 |
16 ' 0 " |
25,000 |
3 " + 3 " |
Perkins 1104D-E44TA( 142) |
– / 11 ' 3 " |
14 " |
– / 19 ' 6 " |
– / 41,500 |
Liftking Mfg Corp |
LK 30P44 |
30,000 |
16 ' 0 " |
30,000 |
3 " + 3 " |
Perkins 1106D-E66TA( 225) |
– / 11 ' 3 " |
14 " |
– / 19 ' 6 " |
– / 46,400 |
Liftking Mfg Corp |
CVS F16 4X4 |
47,600 |
15 ' 0 " |
47,600 |
12 " + 12 " |
Cummins QSB6.7( 220) |
– / 13 ' 0 " |
17 " |
– / 30 ' 9 " |
– / 74,100 |
Liftking Mfg Corp |
LK 35C |
50,000 |
18 ' 0 " |
50,000 |
12 " + 12 " |
Perkins 1106D-E66TA( 225) |
– / 12 ' 6 " |
15 " |
– / 27 ' 0 " |
– / 61,200 |
Liftking Mfg Corp |
LK 50C |
68,000 |
12 ' 0 " |
68,000 |
12 " + 12 " |
Caterpillar C13( 385) |
– / 13 ' 5 " |
15 " |
– / 29 ' 6 " |
– / 100,500 |
Liftking Mfg Corp |
CVS F25 4X4 |
74,250 |
15 ' 0 " |
74,250 |
12 " + 12 " |
Cummins QSB6.7( 220) |
– / 13 ' 10 " |
17 " |
– / 31 ' 8 " |
– / 90,600 |
Liftking Mfg Corp |
LK 67C |
90,000 |
12 ' 0 " |
90,000 |
12 " + 12 " |
Caterpillar C13( 385) |
– / 13 ' 5 " |
15 " |
– / 29 ' 6 " |
– / 127,400 |
Manitou |
MC 25 |
5511 |
18 ' 0.5 " |
5511 |
Optional |
Kubota D1803 Turbo T4( 49) |
6 ' 3 " / 6 ' 3 " |
12 " |
11 ' 3 " / 11 ' 3 " |
9,457 / 9,457 |
Manitou |
MC 30 |
6076 |
18 ' 0.5 " |
6076 |
Optional |
Kubota D1803 Turbo T4( 49) |
6 ' 3 " / 6 ' 3 " |
12 " |
11 ' 3 " / 11 ' 3 " |
9,788 / 9,788 |
Manitou |
MSI 25 T |
5,000 |
21 ' 5 " |
5,000 |
Optio – l |
Kubota D1803 Turbo T4( 49) |
– / 5 ' 11 " |
10.2 " |
8 ' 6 " /- |
8,973 /-- |
Manitou |
MSI 30 T |
6,000 |
15 ' 5 " |
6,000 |
Optio – l |
Kubota D1803 Turbo T4( 49) |
5 ' 11 " / – |
10.6 " |
8 ' 8 " / – |
9,568 / – |
Manitou |
M 30-2 / M 30-4 |
6,063 |
21 ' 4 " |
6,063 |
Standard |
Deutz TD 2.9 LEPA T4( 74) |
6 ' 6 " / 6 ' 6 " |
14 "/ 15 " |
10 ' 2 " / 14 ' 0 " |
11,662 / 12,092 |
Manitou |
M 40-2 / M 40-4 |
8,179 |
19 ' 6 " |
8,179 |
Standard |
Deutz TD 2.9 LEPA T4( 74) |
6 ' 9 " / 6 ' 11 " |
14 " / 17 " |
10 ' 8 " / 14 ' 8 " |
15,695 / 16,290 |
Manitou |
MSI 40 T |
8,179 |
15 ' 5 " |
8,179 |
Optio – l |
Deutz TD 2.9 LEPA T4( 74) |
6 ' 10 " / – |
7.3 " |
9 ' 5 " / – |
15,388 / – |
Manitou |
M 50-2 / M 50-4 |
11,023 |
19 ' 8 " |
11,023 |
Standard |
Deutz TD 2.9 LEPA T4( 74) |
6 ' 9 " / 6 ' 11 " |
14 " / 17 " |
11 ' 2 " / 15 ' 0 " |
17,461 / 18,056 |
Manitou |
MSI 50T |
11,023 |
15 ' 5 " |
11,023 |
Optio – l |
Deutz TD 2.9 LEPA T4( 74) |
6 ' 10 " / – |
7.3 " |
9 ' 8 " / – |
18,563 / – |
Manitou |
M 70-2 |
15,432 |
14 ' 9 " |
15,432 |
Standard |
Deutz TCD 3.6L EPA T4( 74) |
7 ' 0 " / – |
15.3 " |
13 ' 10 " |
21,781 |
Master Craft |
C-05 |
5,000 |
24 ' 0 " |
2,600 |
3 " |
Cat C-4-4-T( 99) |
7 ' 4 " / 7 ' 4 " |
11 " |
14 ' 1 " / 15 ' 1 " |
14,953 / 15,571 |
Master Craft |
MC-05 |
5,000 |
24 ' 0 " |
2,600 |
3 " |
Perkins 3.4T( 74) |
7 ' 0 " / 7 ' 0 " |
11 " |
14 ' 1 " / 15 ' 4 " |
14,953 / 15,571 |
Master Craft |
C-06 |
6,000 |
24 ' 0 " |
3,120 |
3 " |
Cat C-4-4-T( 99) |
7 ' 4 " / 7 ' 4 " |
11 " |
14 ' 1 " / 15 ' 1 " |
15,237 / 15,855 |
Master Craft |
MC-06 |
6,000 |
24 ' 0 " |
3,120 |
3 " |
Perkins 3.4T( 74) |
7 ' 0 " / 7 ' 0 " |
11 " |
14 ' 1 " / 15 ' 4 " |
15,237 / 15,855 |
Master Craft |
C-08 |
8,000 |
24 ' 0 " |
4,160 |
3 " |
Cat C-4-4-T( 99) |
7 ' 4 " / 7 ' 4 " |
11 " |
14 ' 1 " / 15 ' 1 " |
17,467 / 18,085 |
Master Craft |
MC-08 |
8,000 |
24 ' 0 " |
4,160 |
3 " |
Perkins 3.4T( 74) |
7 ' 0 " / 7 ' 0 " |
11 " |
14 ' 1 " / 15 ' 4 " |
17,467 / 18,085 |
Master Craft |
C-10 |
10,000 |
21 ' 0 " |
6,400 |
3 " |
Cat C-4-4-T( 99) |
7 ' 4 " / 7 ' 4 " |
11 " |
14 ' 1 " / 15 ' 1 " |
18,900 / 19,990 |
Master Craft |
MC-10 |
10,000 |
21 ' 0 " |
6,400 |
3 " |
Perkins 3.4T( 74) |
7 ' 5 " / 7 ' 6 " |
11 " |
14 ' 6 " / 17 ' 6 " |
18,900 / 19,990 |
Master Craft |
C-12 |
12,000 |
21 ' 0 " |
7,680 |
3 " |
Cat C-4-4-T( 99) |
7 ' 4 " / 7 ' 4 " |
11 " |
14 ' 1 " / 15 ' 1 " |
18,720 / 20,770 |
Master Craft |
MC-12 |
12,000 |
21 ' 0 " |
7,680 |
3 " |
Perkins 3.4T( 74) |
7 ' 5 " / 7 ' 6 " |
11 " |
14 ' 6 " / 17 ' 6 " |
18,720 / 20,770 |
Master Craft |
MC-14 |
14,000 |
16 ' 0 " |
11,760 |
1 " |
Perkins 3.4T( 120) |
9 ' 0 " |
11.5 " |
– / 21 ' 10 " |
– / 27,500 |
Master Craft |
MC-16 |
16,000 |
16 ' 0 " |
13,440 |
1 " |
Perkins 3.4T( 120) |
9 ' 0 " |
11.5 " |
– / 21 ' 10 " |
– / 27,500 |
Master Craft |
MC-18 |
18,000 |
16 ' 0 " |
15,120 |
1 " |
Perkins 3.4T( 120) |
9 ' 8 " |
11.5 " |
– / 22 ' 6 " |
– / 35,300 |
Master Craft |
MC-20 |
20,000 |
16 ' 0 " |
16,800 |
1 " |
Perkins 3.4TA( 120) |
9 ' 8 " |
11.5 " |
– / 22 ' 6 " |
– / 35,300 |
Noble |
R40 |
4,000 |
21 ' 0 " |
2,350 |
4 " |
Cat 3054C( 99) |
6 ' 3 " / – |
8.3 " |
12 ' 8 " / – |
10,700 / – |
Noble |
RT50 |
5,000 |
22 ' 0 " |
3,000 |
3.8 " |
Perkins 1004D-44T( 99) |
7 ' 9 " / 7 ' 9 " |
11.5 " |
– |
13,429 / 13,429 |
Noble |
R50 |
5,000 |
21 ' 0 " |
3,350 |
4 " |
Cat 3054C( 99) |
6 ' 2.8 " / – |
8.3 " |
12 ' 8 " / – |
11,150 / – |
Noble |
RC60 Lo Pro |
6,000 |
11 ' 0 " |
6,000 |
4 " |
Perkins 1004D-44T( 99) |
6 ' 3 " / – |
9.8 " |
15 ' 3.5 " / – |
13,400 / – |
Noble |
RC60 |
6,000 |
21 ' 0 " |
4,350 |
4 " |
Cat 3054C( 99) |
6 ' 3 " / – |
8.3 " |
12 ' 8 " / – |
11,800 / – |
Noble |
RT60 |
6,000 |
22 ' 0 " |
4,400 |
3.8 " |
Perkins 1004D-44T( 99) |
7 ' 9 " / 7 ' 9 " |
11.5 " |
– |
14,720 / 14,720 |
Noble |
R60 |
6,000 |
20 ' 0 " |
6,000 |
4 " |
Cat 3054C( 99) |
6 ' 10.7 " / 6 ' 6.4 "
( 9.5 " 2WD) 7.3 "
|
15 ' 0 " / 15 ' 6 " |
12,700 / 14,800 |
|
Noble |
RT80 |
8,000 |
30 ' 0 " |
3,300 |
3.8 " |
Perkins 1004D-44T( 99) |
7 ' 9 " / 7 ' 9 " |
11.5 " |
– |
17,346 / 17,346 |
Noble |
R80 |
8,000 |
30 ' 0 " |
3,350 |
4 " |
Cat 3054C( 99) |
6 ' 10.5 " / 6 ' 6.4 "
( 9.5 " 2WD) 7.3 "
|
15 ' 0 " / 15 ' 6 " |
14,100 / 16,000 |
|
Noble |
R100 |
10,000 |
21 ' 0 " |
3,375 |
4 " |
Cat 3054C( 99) |
8 ' 2.3 " / 7 ' 10.2 "
( 9.5 " 2WD) 8.8 "
|
17 ' 8 " / 20 ' 10 " |
17,200 / 18,300 |
|
Noble |
R120 |
12,000 |
21 ' 0 " |
5,000 |
4 " |
Cat 3054C( 99) |
8 ' 2.3 " / 7 ' 10.2 "
( 9.5 " 2WD) 8.8 "
|
17 ' 8 " / 20 ' 10 " |
18,200 / 19,300 |
|
Sellick |
SLP-50 |
5,000 |
22 ' 0 " |
2,500 |
6 " |
Kohler T4( 62) |
7 ' 9 " / 7 ' 9 ' |
12 " |
14 ' 10 " / 15 ' 10 " |
12,900 / 13,150 |
Sellick |
S-60 |
6,000 |
22 ' 0 " |
4,500 |
6 " |
ECOMAX T4( 74) |
7 ' 4 " / 7 ' 4 " |
15 " |
14 ' 10 " / 14 ' 10 " |
14,710 / 14,842 |
Sellick |
SLP-60 |
6,000 |
22 ' 0 " |
4,500 |
6 " |
Kohler T4( 62) |
7 ' 9 " / 7 ' 9 ' |
12 " |
14 ' 10 " / 15 ' 10 " |
13,200 / 13,450 |
Sellick |
S-80 |
8,000 |
22 ' 0 " |
5,700 |
6 " |
ECOMAX T4( 74) |
7 ' 4 " / 7 ' 4 " |
15 " |
14 ' 10 " / 14 ' 10 " |
16,210 / 16,342 |
Sellick |
SLP-80 |
8,000 |
22 ' 0 " |
5,700 |
6 " |
Kohler T4( 62) |
7 ' 9 " / 7 ' 9 ' |
12 " |
14 ' 10 " / 15 ' 10 " |
15,350 / 15,700 |
Sellick |
S-100 |
10,000 |
22 ' 0 " |
8,200 |
6 " |
ECOMAX T4( 74) |
7 ' 4 " / 7 ' 4 " |
15 " |
14 ' 10 " / 14 ' 10 " |
17,850 / 17,982 |
Sellick |
S-120 |
12,000 |
22 ' 0 " |
9,300 |
6 " |
ECOMAX T4( 74) |
7 ' 4 " / 7 ' 4 " |
15 " |
15 ' 3 " / 15 ' 3 " |
20,077 / 20,209 |
