LIFT SPOTLIGHT
Ruthmann T187AE
Ruthmann’ s T187AE allows more work to be completed with less repositioning compared to other access methods, and combines high reach with easy roadability.
Built on a Kenworth T480 chassis, the Ruthmann T187AE delivers a 187-foot working height and a 133-foot horizontal outreach, allowing crews to cover more area without repositioning. At around 60,000 pounds, the unit meets federal bridge law limits and can travel between sites without permitting. The dynamic reach system( DRS) calculates the working envelope in real time based on outrigger positions and platform capacity. Operators can select wind-speed ratings of 28, 35 or 43 miles per hour, and a jack-force limiter reduces ground-bearing pressure for sensitive surfaces.
For taller tasks, the Ruthmann T328AE raises the platform to 328 feet while maintaining the same 133-foot horizontal outreach. It shares the T187’ s DRS envelope management and wind-speed / jack-force limiter options, giving crews enough vertical and horizontal reach to tackle work normally reserved for cranes or suspended access systems.
Ruthmann’ s DRS technology optimizes each machine’ s working envelope by analyzing outrigger position, boom configuration and platform capacity. Ruthmann’ s working envelope adjusts in real time rather than relying on a fixed geometry, allowing reach to vary based on positioning. Standardized components across the product line make maintenance simple. For contractors working on complex projects, these road-legal, high-reach platforms provide an alternative to traditional access methods and are used across sectors such as electric-utility linework, wind energy and telecommunications, among others.
www. ruthmannreachmaster. com
LGMG A43JE
The LGMG A43JE articulating electric boom lift delivers a combination of reach and compact design in the mid-size category. With a platform height of 42 feet, 8 inches and an overall width of 4 feet, 11 inches, the model is among the narrowest machines in its class offering this level of working height. This configuration allows access to confined or space-restricted jobsites, including indoor facilities, urban projects and maintenance environments, while still providing reach associated with larger models.
The A43JE delivers up-and-over clearance of 23 feet, 4 inches, enabling operators to navigate obstacles. The machine comes standard with a 160-degree horizontal rotating jib, along with smooth, intuitive controls, supporting precise positioning and efficient operation in tight spaces. A 441-pound platform capacity accommodates up to two occupants, making it suitable for a range of applications including installation, maintenance and repair work across commercial and industrial settings.
The A43JE is designed for use across a range of jobsites within its height class. The model provides a higher working height than standard 40-foot narrow electric booms and is positioned within a comparable acquisition cost range, supporting fleet flexibility.
This articulated boom machine is powered by a zero-emission electric drive system, making it well-suited for indoor use and environments with strict emissions requirements. LGMG Hostile Environment Kit comes standard and includes protective features strategically designed to help safeguard against external damage while extending machine life.
www. lgmgna. com
JCB T65D
The JCB T65D telescopic boom lift is designed for applications that demand capacity and outreach, supporting work on large-scale construction, industrial and infrastructure projects where reach and stability are critical.
At the center of its latest update is a new calibration approach. Previously, recalibration required technicians to transport and handle up to 1,000 pounds of test weights when a machine fell out of calibration. The updated system changes this process, allowing calibration to be completed with a lower applied load starting at 120 pounds. This reduces setup time and limits the physical demands placed on service personnel.
The system is enabled by a patented software solution integrated directly into the machine’ s control interface. Through a guided on-screen process, technicians can complete calibration without external tools or specialized equipment. This integration reflects a broader emphasis on intuitive operator interaction, where key functions and diagnostics are accessible directly through the machine’ s onboard display, helping streamline both operation and service.
Beyond calibration, the T65D features“ extra” capacity, allowing operators to manage different load thresholds depending on boom position and working envelope. This provides added flexibility on the jobsite, enabling a single machine to handle a wider range of tasks. Combined with a JCB 444 74-horsepower engine for power on congested and uneven terrain, these features support a balanced focus on performance, usability and uptime.
www. jcb. com
